Min. Poloaiga:1 Piece/Pieces
Faataʻitaʻiga No.: BA104S01-100
B104S01-100 o le 10.4-inisi LCD module oloa na faalauiloa e BEE Technory Stura Co., LTD. (Boe) faʻaaogaina A-SI TTT-LCD Tekonolosi. E tuʻuina atu i tua i tua, leai se tua o le tiʻetiʻe ma leai se paʻi atu. B104S01-100 faʻaalia se faʻaiuga o le 800 (RGB) × 600 (svga), o se itu faʻavae o le 4: 3 (lautele: maualuga) o loʻo faʻatulaga i luga .1 Faʻamatalaina e BEE ia Tesema 12, 2014. O lana faʻaaliga vaega o le 211.2 × 158.4 (lautele ×) MM, o le maualuga) × 5.9 (mafiafia) mm, togafitiga o luga e manino, oloa o le mamafa o le 288g (masani (masani.). Vave lenei oloa faʻaaogaina se 6s6p fefiloi itu ulufale ulufale (pito i luga), o le ola o le moli moli o le 50k itula, leai se toe oso i ai. B104S01-100 UDPTS LVDS (1 ch, 6/8-bit) faʻailoga faʻapitoa, o le aofaʻi o le 20 pine, o loʻo faʻaaogaina le talimalo o le 3.3v.). O le masani ona o le fua faatatau o le fv o le 60hz. E faʻagaioia i -20 ° C i le 70 ° C ma faleoloa i -30 ° C i le 80 ° C. O lenei faʻataʻitaʻiga o loʻo fautuaina mo le faʻaaogaina i alamanuia ma faʻafomaʻi ona o lona paʻepaʻe ki, luga o le 50,000 itula o le ola lanu efuefu, ma isi foliga.
| brand | BOE | Model name | BA104S01-100 |
| size | 10.4 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 800(RGB)×600 [SVGA] 96PPI | Pixel configuration | RGB vertical bar |
| Display Area | 211.2×158.4 mm (H×V) | Surface treatment | Clear |
| Visual size | 215.0×162.0 mm (H×V) | Contrast Ratio | 800:1 (Typ.) (TM) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Outline dimension | 236×176.9×5.9 mm (H×V×D) |
| Viewing Angle | 70/70/60/70 (Typ.)(CR≥10) | ||
| Signal interface | LVDS (1 ch, 6/8-bit) ,erminal, 20 pins | ||
| work environment | Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C |
O mea nei e tutusa tutusa ma faʻataʻitaʻiga ma tapulaa
| brand | BOE | Model name | AV104X0M-N10 |
| size | 10.4 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1024(RGB)×768 (XGA) 123PPI | Pixel configuration | RGB vertical bar |
| Display Area | 210.4 × 157.8 (H×V) mm | Surface treatment | / |
| Visual size | 215.4 × 161.8 (H×V) mm | Contrast Ratio | 1100:1 (Typ.) (TM) |
| Brightness(cd/m²) | 600cd/m²(Typ.)or customized | Outline dimension | 230 × 180.2(H×V) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) | ||
| Signal interface | LVDS (1 ch, 6/8-bit) ,erminal, 20 pins | ||
| work environment | Storage temperature: -40 to 95 °C Operation Temperature: -30 to 85 °C |
| brand | BOE | Model name | TDA104-001V02 |
| size | 10.4 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1024(RGB)×768 (XGA) 123PPI | Pixel configuration | RGB vertical bar |
| Display Area | 210.4 × 157.8 (H×V) mm | Surface treatment | / |
| Visual size | / | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Brightness(cd/m²) | 900cd/m²(Typ.)or customized | Outline dimension | 235×173×10.5mm(H×V×D) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) | ||
| Signal interface | LVDS (1 ch, 8-bit) ,erminal, 20 pins | ||
| work environment | Storage temperature: -55 to 85 °C Operation Temperature: -40 to 80 °C |
Fort Fusi: BOE BA104S01-100 GREICELOCKING TLM-LCD Panene, Taugofie, Coprines Swed ScD, LCD mata mo fafo , LCD Panel, LCD module, maualuga susulu malamalama.
