Oloa Uiga

Faataʻitaʻiga No.: EV101WXM-N81

Afifiina & Faaooina

Faʻatau Iunite:

Piece/Pieces

Oloa Folasaga

EV101WXM-N81 o le 10.1-inisi LCD module faaaoga A-SI TTT-LCD Techno. E tuʻuina atu i tua o le tuala, e aofia ai ma le taʻavale avetaʻavale taʻavale, leai se paʻi. Faʻaalia le tali o le 1280 (RGB) × 800 (WXGA), Stane Roati o 16:10 (lautele: maualuga) O lana faʻaaliga vaega e tele le 216.96 × 135.6 (lautele × ×) MM, o le tele o le tele o le 219.4.9 (lautele) o le (lautele) o le sili (o le lautele) M × (Toʻatasi.). I le tulaga o le pito i tua, o lenei oloa e faʻaaogaina ai le Uled Ituʻaiga ulufale malamalama malamalama ma se olaga o 50k itula, e aofia ai le aveina o le avetaavale. EV101WXM-N81 faʻaaogaina lvds (1 ch, 8-bit) faʻailo, aofaʻiga o le 20 pine, faʻaaogaina le nofoaga o le 3.3v (e masani ai.). O le masani ona o le fua faatatau o le fv o le 60hz. E faʻagaioia i -20 ° C i le 70 ° C ma faleoloa i -30 ° C i le 80 ° C. Faʻavae i luga o lona paʻepaʻe toe kiwew, o le olaga e sili atu nai lo le 50,000 itula.

R-fetu na tupu mai le Shenzhen, Saina, o matou o le Prostrust Promptar of High High Explight LCD, e aofia ai le maualuga o le LCD, tumu i fafo i fafo Faapipiiina LCD, Alamanuia Maualuga Tft-LCD, manino LCD ma Faaali le Fid, faaluaina le LCD, maualuga-malamalama LCD. I se faapuupuuga, tulai atu e sili atu nai lo le 5 tausaga o le maualuga susulu malamalama atu module tekinolosi aafiaga, 8 tausaga ma atinaʻe maualuga, 10 tausaga le maualuga o le tino.

brand	BOE	Model name	EV101WXM-N81
size	10.1 inch	Screen type	a-Si TFT-LCD,LCD module
resolution ratio	1280(RGB)×800, WXGA, 149PPI	Pixel configuration	RGB vertical bar
Display Area	216.96×135.6(H×V)mm	Surface treatment	/
Visual size	233.2×152.9×10.4(H×V×D) mm	Contrast Ratio	900:1 (Typ.) (TM)
Brightness(cd/m²)	500cd/m²(Typ.)or customized	Outline dimension	233.2×152.9×10.4(H×V×D)mm
Viewing Angle	85/85/85/85 (Typ.)(CR≥10)
Signal interface	LVDS (1 ch, 8-bit) ,erminal, 20 pins
work environment	Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C

O le tutusa o le tele o faʻataʻitaʻiga ma tapulaʻa o loʻo mulimuli mai

brand	BOE	Model name	EV101WUM-N20
size	10.1 inch	Screen type	a-Si TFT-LCD,LCD module
resolution ratio	1920(RGB)×1200, WUXGA, 224PPI	Pixel configuration	RGB vertical bar
Display Area	216.806×135.504mm(H×V)	Surface treatment	/
Visual size	/	Contrast Ratio	900:1 (Typ.) (TM)
Brightness(cd/m²)	600cd/m²(Typ.)or customized	Outline dimension	229.45×149.22(H×V)mm
Viewing Angle	80/80/80/80(Typ.)(CR≥10)
Signal interface	LVDS (1 ch, 8-bit) ,erminal, 45 pins
work environment	Storage temperature: -25 to 80 °C Operation Temperature: -20 to 70 °C

brand	BOE	Model name	AT101WSM-N11-58P0
size	10.1 inch	Screen type	a-Si TFT-LCD,LCD module
resolution ratio	1024(RGB)×600, WSVGA, 117PPI	Pixel configuration	RGB vertical bar
Display Area	222.72×125.28mm(H×V)	Surface treatment	Fog surface，Hard coating (3H)
Visual size	226×128.6(H×V)mm	Contrast Ratio	500:1 (Typ.) (TM)
Brightness(cd/m²)	500cd/m²(Typ.)or customized	Outline dimension	235×144.9×5.44mm(H×V×D)
Viewing Angle	80/80/60/70(Typ.)(CR≥10)
Signal interface	LVDS (1 ch, 6/8-bit) , 60 pins , FPC
work environment	Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C

brand	BOE	Model name	EV101WXM-N82
size	10.1 inch	Screen type	a-Si TFT-LCD,LCD module
resolution ratio	1280(RGB)×800 [WXGA] 149PPI	Pixel configuration	RGB vertical bar
Display Area	216.96 × 135.6 mm (H×V)	Surface treatment	/
Visual size	/	Contrast Ratio	900:1 (Typ.) (TM)
Brightness(cd/m²)	500cd/m²(Typ.)or customized	Outline dimension	228.6 ×149.2×6 mm (H×V×D)
Viewing Angle	85/85/85/85(Typ.)(CR≥10)
Signal interface	LVDS (1 ch, 8-bit) ,erminal, 40 pins
work environment	Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C
