Min. Poloaiga:1 Piece/Pieces
Faataʻitaʻiga No.: MG2350S01-1
O le galuega o le MG2350s01-1 o le 0 ~ 50 ° C, ma le teuina o le vevela o -20 ~ 60 ° C. E talafeagai mo le numera numera ma le tipiina o pa.
O le faʻaaliga o le MG2350s01-1 o 1920 (RGB) × 360, o lana faʻaaliga vaega o le 59.62 (lautele) o le (lautele) Mate (haze 25%).
MG2350S01-1 puptts LVDs (2 ch, 8-bit) faʻailoga faʻailo, o le aofaʻi o le 30 pini, fesoʻotaʻi e le uati o le 12.0v (masani i le dricage e 12.0v (masani.).
| brand | CSOT | Model name | MG2350S01-1 |
| size | 23.5inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1920(RGB)×360 | Pixel configuration | RGB vertical bar |
| Display Area | 584.64×109.62(H×V)mm | Surface treatment | Fog surface(Haze 25%) |
| Visual size | / | Contrast Ratio | 4000:1 (Typ.) (TM) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Outline dimension | 596.42×122.67(H×V)mm |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) | Backlight type | WLED,Including LED driver |
| Signal interface | 30 pins LVDS (2 ch, 8-bit)，erminal | work environment | Storage temperature: -20 to 60 °C Operation Temperature: 0 to 50 °C |
| supply voltage | 12.0V (Typ.) |
|
|
Fortt pine: 23.5 "CSOT MG2350S01-1 Faʻafaigofie, Saina, taugofie, tau, o loʻo feagai ma le BCD TLODS. , Tatala le faʻavaʻa LCD modules , LCD Vaega, LCD module, maualuga pupula faʻaali.
